Oxyll® dual-selector ball flowmeters are recommended for use in oxygen therapy. They are lightweight, easy to use, efficient, and accurate. They compensate for variations in line pressure, allowing full line pressure, maintaining pressure, and delivering the selected flow rate to the patient at atmospheric pressure, through a mask, nasal cannula, nebulizer, humidifier, etc.

They have been designed to save time and oxygen through a rotary control that allows switching between direct output to the mask, a nebulizer device, or a humidifier, without interrupting the oxygen supply during this operation.

Description:

• Matt chrome-plated brass body.
• Polyamide regulation control.
• Outer and inner tube in polycarbonate.
• Stainless steel ball.
• DISS outlet in matt chrome-plated brass.
• Latex free.

Optional accessories:

• Dimensions (Width x Height) : 125 x 154 mm
• Weight : 590 g
• Gas options : O₂ and Air
• Fittings : BS, NF, DIN and SS (Other connections consult) | No connection (Whitworth thread  G1/8” F)
• Outlet fitting : DISS O 2  9/16” – 18h UNF | DISS connector for tube O 2 and Air
• Inlet pressure : 4.5 bar – 65 psi – 450 kPa
• Accuracy : ±10%
• Scales from :  From 0 to 5 L/min | 0 to 15L/min | 0 to 30L/min
• Option : Rail coupling
